DORMER - 1.8mm 118° High Speed Steel Jobber Drill - Exact Tool & Supply

DORMER - 1.8mm 118° High Speed Steel Jobber Drill


Item #: 80975980
Brand: DORMER
Model #: 0376867

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (mm) 1.80
Drill Bit Size (Decimal Inch) 0.0709
Drill Point Angle 118
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Bright
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (mm) 22.00
Flute Length (Decimal Inch) 0.8668
Overall Length (mm) 46.00
Overall Length (Decimal Inch) 1.8124
Flute Length x Diameter Ratio 4xD
Spiral Type Regular Spiral
Specification Designation DIN
Web Configuration Tapered
Drill Bit Diameter Tolerance (mm) 0.000 to -0.014
Number of Flutes 2
Specification Number DIN 338
Material Grade M2
Series/List A002
$3.87
