National Twist Drill - 1.65mm 118° High Speed Steel Jobber Drill - Exact Tool & Supply

National Twist Drill - 1.65mm 118° High Speed Steel Jobber Drill


Item #: 66123761
Brand: National Twist Drill
Model #: 012634AW

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Oxide prevents chip building, galling and welding on the workpiece. It is commonly used on low carbons, stainless steel and ferrous metals.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (mm) 1.65
Drill Bit Size (Decimal Inch) 0.0650
Drill Point Angle 118
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Oxide
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 25/32
Flute Length (mm) 19.84
Flute Length (Decimal Inch) 0.7813
Overall Length (mm) 42.86
Overall Length (Decimal Inch) 1.6875
Overall Length (Inch) 1-11/16
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) -0.0005 to 0.0000
Series/List 206M
$3.39

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
