Cle-Force - 1/8" 135° High Speed Steel Jobber Drill - Exact Tool & Supply

Cle-Force - 1/8" 135° High Speed Steel Jobber Drill


Item #: 57608770
Brand: Cle-Force
Model #: C69046

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Oxide/gold finish provides a polished finish and prevents chip building, galling and welding on a workpiece. It is commonly used on low carbon, stainless steel and ferrous metals.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (Inch) 1/8
Drill Bit Size (Decimal Inch) 0.1250
Drill Point Angle 135
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Oxide/Gold
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 1-5/8
Flute Length (mm) 41.28
Flute Length (Decimal Inch) 1.6250
Overall Length (mm) 69.85
Overall Length (Decimal Inch) 2.7500
Overall Length (Inch) 2-3/4
Point Type Split Point
Shank Diameter (mm) 3.18
Shank Diameter (Inch) 1/8
Shank Diameter (Decimal Inch) 0.1250
Spiral Type Regular Spiral
Shank Length (mm) 28.58
Shank Length (Decimal Inch) 1.1252
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) +0.0000 to -0.0005
Web Thinning Web-Thinned
Drill Bit Grade Heavy Duty
Series/List 1604
$1.59
