Cle-Line - #28 118° High Speed Steel Jobber Drill - Exact Tool & Supply

Cle-Line - #28 118° High Speed Steel Jobber Drill


Item #: 73313637
Brand: Cle-Line
Model #: C22682

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Oxide prevents chip building, galling and welding on the workpiece. It is commonly used on low carbons, stainless steel and ferrous metals.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (Wire) #28
Drill Bit Size (Decimal Inch) 0.1405
Drill Point Angle 118
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Oxide
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 1-3/4
Flute Length (mm) 44.45
Flute Length (Decimal Inch) 1.7500
Overall Length (mm) 73.03
Overall Length (Decimal Inch) 2.8750
Overall Length (Inch) 2-7/8
Point Type Standard
Shank Diameter (mm) 3.57
Shank Diameter (Decimal Inch) 0.1405
Spiral Type Regular Spiral
Shank Length (mm) 28.57
Shank Length (Decimal Inch) 1.1248
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) +0.0000 to -0.0007
Web Thinning Web-Thinned
Drill Bit Grade General Purpose
Series/List 1899
$1.53

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
