Cle-Line - 25/64" 135° High Speed Steel Jobber Drill
Item #: 57593337
Brand: Cle-Line
Model #: C18021
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Oxide/gold finish provides a polished finish and prevents chip building, galling and welding on a workpiece. It is commonly used on low carbon, stainless steel and ferrous metals.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
| Product Specifications | |
|---|---|
| Drill Bit Size (Inch) | 25/64 |
| Drill Bit Size (Decimal Inch) | 0.3906 |
| Drill Point Angle | 135 |
| Drill Bit Material | High Speed Steel |
| Drill Bit Finish/Coating | Oxide/Gold |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Shank Type | Straight |
| Coolant Through | No |
| Flute Length (Inch) | 3-3/4 |
| Flute Length (mm) | 95.25 |
| Flute Length (Decimal Inch) | 3.7500 |
| Overall Length (mm) | 130.18 |
| Overall Length (Decimal Inch) | 5.1250 |
| Overall Length (Inch) | 5-1/8 |
| Point Type | Split Point |
| Shank Diameter (mm) | 9.92 |
| Shank Diameter (Inch) | 25/64 |
| Shank Diameter (Decimal Inch) | 0.3906 |
| Spiral Type | Regular Spiral |
| Shank Length (mm) | 34.92 |
| Shank Length (Decimal Inch) | 1.3748 |
| Web Configuration | Tapered |
| Drill Bit Diameter Tolerance (Decimal Inch) | +0.0000 to -0.0010 |
| Web Thinning | Web-Thinned |
| Drill Bit Grade | Heavy Duty |
| Series/List | 1878 |
