Sandvik Coromant - 17.8mm 147° Solid Carbide Jobber Drill - Exact Tool & Supply

Sandvik Coromant - 17.8mm 147° Solid Carbide Jobber Drill


Item #: 49559933
Brand: Sandvik Coromant
Model #: 6040488

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Titanium Aluminum Nitride (TiAlN) has a higher hardness and oxidation temperature versus TiN and TiCN. As a result, it is particularly advantageous for higher speed operations in a variety of steel machining applications.
Product Specifications
Drill Bit Size (mm) 17.80
Drill Bit Size (Decimal Inch) 0.7008
Drill Point Angle 147
Drill Bit Material Solid Carbide
Drill Bit Finish/Coating TiAlN
Cutting Direction Right Hand
Shank Type Cylindrical
Coolant Through Coolant Through
Flute Length (mm) 93.00
Flute Length (Decimal Inch) 3.6614
Overall Length (mm) 143.00
Overall Length (Decimal Inch) 5.6299
Flute Length x Diameter Ratio 4xD
Shank Diameter (mm) 18.00
Shank Diameter (Decimal Inch) 0.7087
Maximum Drilling Depth (Decimal Inch) 2.9606
Maximum Drilling Depth (mm) 75.20
Drill Point Length (mm) 2.80
Drill Point Length (Decimal Inch) 0.1102
Number of Flutes 2
Series/List CoroDrill 860
$656.06
