Cleveland - #28 118° High Speed Steel Jobber Drill - Exact Tool & Supply

Cleveland - #28 118° High Speed Steel Jobber Drill

Item #: 63685283
Brand: Cleveland
Model #: C71128

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Oxide prevents chip building, galling and welding on the workpiece. It is commonly used on low carbons, stainless steel and ferrous metals.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (Wire) #28
Drill Bit Size (Decimal Inch) 0.1405
Drill Point Angle 118
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Oxide
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 1-3/4
Flute Length (mm) 44.45
Flute Length (Decimal Inch) 1.7500
Overall Length (Inch) 2-7/8
Point Type Standard
Shank Diameter (Decimal Inch) 0.1405
Spiral Type Regular Spiral
Specification Designation ANSI
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) -0.0007 to 0.0000
Web Thinning Web-Thinned
Drill Bit Grade General Purpose
Series/List 2001G
