Scientific Cutting Tools - 2-1/4 - 12" Port, 3.05" Spotface Diam, 1-3/4" Tube Outside Diam, Reamer Pilot, Carbide Tipped Porting Tool
Item #: 44064723
Brand: Scientific Cutting Tools
Model #: MS33649-28RA
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
| Product Specifications | |
|---|---|
| Port Standard Designation | AS 5202; MS 33649 |
| Pilot Type | Reamer |
| Port Thread Size (Decimal Inch) | 2.2500-12 |
| Port Thread Size (Inch) | 2-1/4 - 12 |
| Tool Material | Carbide-Tipped |
| Tube Dash Number | 28.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 1.750 |
| Tube Outside Diameter Compatibility (Inch) | 1-3/4 |
| Minimum Pilot Diameter (Decimal Inch) | 2.1740 |
| Maximum Pilot Diameter (Decimal Inch) | 2.2755 |
| Spotface Diameter (Decimal Inch) | 3.0500 |
| Pilot Length (Decimal Inch) | 1.1300 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | AlTiN+ |
| Head Length (Decimal Inch) | 2.4200 |
| Overall Length (Decimal Inch) | 4.9200 |
| Shank Diameter (Decimal Inch) | 1.2500 |
| Shank Length (Decimal Inch) | 2.5000 |
| Seal Angle | 30 |
| Thread Type | UNJ |
| Flute Type | Straight |
| Number of Flutes | 4 |
