Rocky Mountain Twist - 1/16" 135° High Speed Steel Jobber Drill - Exact Tool & Supply

Rocky Mountain Twist - 1/16" 135° High Speed Steel Jobber Drill

Item #: 57627457
Brand: Rocky Mountain Twist
Model #: 95003300

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (Inch) 1/16
Drill Bit Size (Decimal Inch) 0.0625
Drill Point Angle 135
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Bright
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 7/8
Flute Length (Decimal Inch) 0.8750
Overall Length (Decimal Inch) 1.8750
Overall Length (Inch) 1-7/8
Point Type Standard
Shank Diameter (Inch) 1/16
Shank Diameter (Decimal Inch) 0.0625
Spiral Type Regular Spiral
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) +0.0000 to -0.0005
Number of Flutes 2
Drill Bit Grade Heavy Duty
Series/List JH500
