Walter-Titex - 2.2mm, 140° Point, Solid Carbide Micro Drill Bit - Exact Tool & Supply

Walter-Titex - 2.2mm, 140° Point, Solid Carbide Micro Drill Bit


Item #: 69973220
Brand: Walter-Titex
Model #: 5932197

Features and Benefits

Solid carbide provides better rigidity than High Speed Steel (HSS). It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
AlTiN micro point is a special coating for small drills with extremely low friction. It is one of the most abrasive-resistant and hardest of the coatings.
Spiral flute reamers are used in blind and through-hole operations. They are used to bridge interrupted cuts.
Regular, also known as medium spiral bits, are used in general purpose applications. They are used on soft, nonferrous materials.
Straight shanks are used for general purpose applications. The shank is smaller than the drill bit diameter. They are used with portable drills and drill presses on ferrous and non-ferrous materials.
Product Specifications
Drill Bit Size (Decimal Inch) 0.0866
Drill Bit Size (mm) 2.20
Shank Diameter (mm) 3.00
Drill Point Angle 140
Drill Bit Material Solid Carbide
Drill Bit Finish/Coating AlTiN Micro Point
Cutting Direction Right Hand
Overall Length (mm) 63.00
Flute Length (mm) 25.00
Through Coolant Yes
Flute Type Spiral
Spiral Type Regular Spiral
Point Type X-treme DM
Maximum Drilling Depth (mm) 21.00
Shank Length (mm) 34.00
Shank Type Straight
Web Configuration Tapered
Drill Bit Diameter Tolerance (mm) m7
Specification Number DIN 6535HA; DIN 6537L
Material Grade K30F
Series/List A6489AMP
