Emuge - 63/64" Tap Shank Diam, 0.7874" Tap Square Size, #5 Tapping Adapter - 1.8898" Projection, 3-15/16" Tap Depth, 4.3701" OAL, 2.3622" Shank OD, Through Coolant, Series EM05
Item #: 52353299
Brand: Emuge
Model #: F0565118
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Adapter Size | 5 |
| Tap Shank Diameter (mm) | 25.00 |
| Tap Shank Diameter (Decimal Inch) | 0.9843 |
| Tap Square Size (mm) | 20.00 |
| Tap Square Size (Decimal Inch) | 0.7874 |
| Quick Change | Yes |
| Projection (mm) | 48.00 |
| Projection (Decimal Inch) | 1.8898 |
| Tap Depth (mm) | 100.00 |
| Tap Depth (Decimal Inch) | 3.9370 |
| Series | EM05 |
| Overall Length (mm) | 111.00 |
| Overall Length (Decimal Inch) | 4.3701 |
| Flange Diameter (mm) | 92.00 |
| Flange Diameter (Decimal Inch) | 3.6221 |
| Outside Shank Diameter (mm) | 60.00 |
| Outside Shank Diameter (Decimal Inch) | 2.3622 |
| Through Coolant | Yes |
| PSC Code | 5136 |
