Climax Metal Products - M4 Thread, 6mm Bore Diam, 13/16" OD, Shaft Locking Device - 3 Screws, 1,479 Lb Axial Load, 15/16" OAW, 0.394" Thrust Ring Width, 175 Ft/Lb Max Torque
Item #: 51320976
Brand: Climax Metal Products
Model #: C193M-6
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M4 |
| Bore Diameter (mm) | 6.000 |
| Outside Diameter (Decimal Inch) | 0.8125 |
| Thrust Ring Width (Decimal Inch) | 0.394 |
| Overall Width (Decimal Inch) | 0.9375 |
| Axial Load Lbs (Pounds) | 1479 |
| Maximum Torque (Ft/Lb) | 175 |
| Number of Screws | 3.000 |
| Contact Pressure on Hub (psi) | 12252.000 |
| Contact Pressure on Shaft (psi) | 42143.000 |
| Screw Seating Torque (In/Lb) | 480.000 |
