Climax Metal Products - M4 Thread, 1/2" Bore Diam, 1-1/16" OD, Shaft Locking Device - 4 Screws, 2,191 Lb Axial Load, 1-3/16" OAW, 0.394" Thrust Ring Width, 548 Ft/Lb Max Torque
Item #: 51320737
Brand: Climax Metal Products
Model #: C193E-050
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M4 |
| Bore Diameter (Decimal Inch) | 0.5000 |
| Outside Diameter (Decimal Inch) | 1.0625 |
| Thrust Ring Width (Decimal Inch) | 0.394 |
| Overall Width (Decimal Inch) | 1.1875 |
| Axial Load Lbs (Pounds) | 2191 |
| Maximum Torque (Ft/Lb) | 548 |
| Number of Screws | 4.000 |
| Contact Pressure on Hub (psi) | 13881.000 |
| Contact Pressure on Shaft (psi) | 29496.000 |
| Screw Seating Torque (In/Lb) | 528.000 |
