Brand: Widia / Part #: 3539162
Item #: 98031503
Brand: Widia
Model #: 3539162
Product Specifications
| Internal or External | External |
| Hand of Holder | Right Hand |
| Maximum Groove Width (mm) | 2.00 |
| Minimum Groove Width (mm) | 2.00 |
| Toolholder Style | WMTCR |
| Tool Material | Steel |
| Insert Holding Method | Clamp |
| Compatible Insert Size Code | S200 |
| Insert Compatibility | WMTS200M2P02PT |
| Shank Height (mm) | 12.00 |
| Shank Length (mm) | 74.000 |
| Shank Width/Diameter (mm) | 12.00 |
| Series | WMT |
| Overall Length (mm) | 100.0000 |
| Cutting Tool Application | Grooving; Cut-Off; Turning |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.4720 |
| Head Length (mm) | 27.70 |
| Primary Workpiece Material | Universal |
| Insert Seat Size | 2.0 |
| Coolant Through | No |
