Single Acting Rodless Air Cylinder: 1" Bore, 2" Stroke, 150 psi Max, 1/8-27 NPT Port, Side Leg - Horizontal Mount
Item #: 85493153
Brand: Schrader Bellows
Model #: 033510199
Product Specifications
| Type | Single Acting |
| Bore Size (Decimal Inch) | 1.000 |
| Bore Size (Inch) | 1 |
| Rod Diameter (Decimal Inch) | 0.3100 |
| Stroke Length (Inch) | 2 |
| Mounting Style | Side Leg - Horizontal |
| Port Size | 1/8-27 |
| Port Type | NPT |
| Length (Decimal Inch) | 4.580 |
| Material | Bronze; Bronze/Steel; Steel |
| Seal Material | Nitrile butadiene rubber |
| Maximum Working Pressure (psi) | 150 |
| Style | Male |
| UNSPSC Code | 27131701 |
| Country of Origin | UNITED STATES |
