Circuit Breaker, 20 Amps, Number of Poles: 2, 347/600VAC AC Voltage Rating
Item #: 482G42
Brand: SQUARE D
Supplier #: BJA260201
Exact Tooling IR#: 08
| Product Specifications | |
|---|---|
| Item | Circuit Breaker |
| Amps | 20 |
| Number of Poles | 2 |
| Circuit Breaker Type | Standard |
| AC Voltage Rating | 347/600VAC |
| DC Voltage Rating | Not Rated |
| For Use With | Industrial Control Panels, Electrical Distribution Equipment |
| Series | PowerPact B |
| Trip Type | Thermal Magnetic |
| Terminal Connection | Load Side Lug |
| Max. AIR Rating | 100 kA |
| Phase Connection | AB |
| Mounting | Clip-On |
| Height | 9.70" |
| Width | 2.97" |
| Depth | 5.16" |
| Min. Wire Size | 14 AWG |
| Max. Wire Size | 2/0 AWG |
| Instantaneous Trip | Fixed |
| Frame Size | 20/BJ |
| Phase | 1 |
| Standards | UL Listed, CSA Certified, CCC, IEC, EAC, NOM |
| UNSPSC # | 39121616 |
| Country of Origin | Mexico |
