Parlec - 2.52 Inch Body, 5/8 Inch Boring Bar Hole Diameter, Manual Single Cutter Boring Head - 0.354 to 1.89 Inch Bore Diameter, Integral Shank, Modular Connection Shank
Item #: 43907013
Brand: Parlec
Model #: BTK-PC6S948B
Exact Tooling IR#: 04
Features and Benefits
Modular connections allow for single tap chucks to accept various tap shank diameters without changing machine tool holding set-ups.
| Product Specifications | |
|---|---|
| Type | Single Cutter Boring Head |
| Actuation Type | Manual |
| Body Diameter (mm) | 64.01 |
| Body Diameter (Decimal Inch) | 2.5200 |
| Boring Bar Hole Diameter (Inch) | 5/8 |
| Boring Bar Hole Diameter (Decimal Inch) | 0.6250 |
| Minimum Bore Diameter (Decimal Inch) | 0.3540 |
| Maximum Bore Diameter (Decimal Inch) | 1.8900 |
| Mount Type | Integral Shank |
| Shank Type | Modular Connection |
| Number of Pieces | 1 |
| Includes | (1) 10mm Steel Boring Bar; (1) 12mm Steel Boring Bar; (1) 14mm Steel Boring Bar; (1) 5/8 Inch Steel Boring Bar; (1) 5/8 Inch to 10mm Reduction Bushing; (1) 5/8 Inch to 12mm Reduction Bushing; (1) 5/8 Inch to 14mm Reduction Bushing |
| Projection (Decimal Inch) | 2.2400 |
