Atlas Workholding - 4 Jaw 12" Diam A-6 Lathe Chuck
Item #: 43490002
Brand: Atlas Workholding
Model #: 4ATL12-A6
Product Specifications
| Chuck Diameter (Decimal Inch) | 12.0000 |
| Number of Jaws | 4 |
| Mount | A-6 |
| Through-Hole Diameter (Decimal Inch) | 3.5800 |
| Chuck Actuation Style | Drawbar |
| Jaw Interface Type | 1.5mm x 60 Serrated |
| Minimum Jaw Capacity (Decimal Inch) | 1.0230 |
| Maximum Jaw Capacity (Decimal Inch) | 12.0000 |
| Jaw Stroke Diameter (Decimal Inch) | 0.4170 |
| Piston Stroke Length (Decimal Inch) | 0.9050 |
| Maximum Drawbar Pulling Force (lbf) | 12813.00 |
| Maximum Static Gripping Force (lbf) | 33047.00 |
| Maximum RPM | 3300 |
| Body Material | Steel |
