Samchully - 3 Jaw, 304mm Chuck Diam, Plain Back Mount, 0mm Through Hole Diam, Drawbar Hydraulic Power Lathe Chuck - 1.5mm x 60° Serrated Jaw Interface, 2,500 RPM, Steel Body
Item #: 41809351
Brand: Samchully
Model #: HCL12
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Chuck Diameter (mm) | 304.00 |
| Number of Jaws | 3 |
| Mount | Plain Back |
| Through-Hole Diameter (mm) | 0.00 |
| Chuck Actuation Style | Drawbar |
| Operation Type | Hydraulic |
| Jaw Interface Type | 1.5mm x 60 Serrated |
| Jaw Stroke Diameter (mm) | 19.40 |
| Piston Stroke Length (mm) | 30.00 |
| Maximum Static Gripping Force (kN) | 111.00 |
| Maximum Static Gripping Force (lbf) | 0.49 |
| Maximum RPM | 2500 |
| Body Material | Steel |
| Power Cylinder Compatibility | Y1530R(RE) |
| Includes | T-Nuts; Mounting Bolts; Master Jaws; Soft Top Jaws; Handle |
