Turning Insert: RCMH86K KCP25C, Carbide
Item #: 84694769
Brand: Kennametal
Model #: 7088767
Product Specifications
| ANSI Insert Code | RCMH |
| ISO Insert Code | RCMH |
| Relief Angle | 7.000 |
| Insert Style | RCMH |
| Corner Radius (mm) | 12.70 |
| Corner Radius (Inch) | 1/2 |
| Corner Radius (Decimal Inch) | 0.5000 |
| Included Angle | 360.00 |
| Manufacturer Grade | KCP25C |
| Coating/Finish | MT-TiCN |
| Insert Hand | Neutral |
| Insert Thickness (Inch) | 3/8 |
| Insert Thickness | 9.53 |
| Insert Thickness (Decimal Inch) | 0.3750 |
| Series | Screw-On Inserts |
| Inscribed Circle (Decimal Inch) | 1.0000 |
| Inscribed Circle (Inch) | 1 |
| Inscribed Circle (mm) | 25.40 |
| Insert Material | Carbide |
| Insert Shape | Round |
| Side Clearance | Positive |
| Number Of Cutting Edges | 1 |
| Insert Shape Code | R |
| Insert Holding Method | Screw |
| Width (Inch) | 1 |
| Clearance Code | C |
| Tolerance Code | M |
| Rake | Negative |
| Insert Length (Decimal Inch) | 1.0000 |
| Insert Length (Inch) | 1 |
| Insert Length (mm) | 25.40 |
| Chip Breaker | K |
| Rake Angle | 0 |
| Cutting Edge Style | Honed |
| Width (Decimal Inch - 4 Decimals) | 1.0000 |
| Width (mm - 2 Decimals) | 25.40 |
| UNSPSC Code | 23242105 |
| Insert Size Code | 86 |
| Country of Origin | UNITED STATES |
