Corner Chamfer End Mill Head: 0.6299″ Dia, 45 °, 4 Flute S10, TiAlN Finish, Helical Flute, Series VEE
Item #: 29162096
Brand: Tungaloy
Model #: 6779141
Product Specifications
| Mill Diameter (mm) | 16.00 |
| Chamfer Width (mm) | 0.60 |
| Mill Diameter (Decimal Inch) | 0.6299 |
| Chamfer Angle | 45 |
| Length of Cut (mm) | 12.00 |
| Connection Type | S10 |
| Overall Length (mm) | 20.50 |
| Centercutting | Yes |
| Flute Type | Helical |
| Series | VEE |
| Helix Angle | 38 |
| Number Of Flutes | 4 |
| Coating/Finish | TiAlN |
