Dumont Minute Man - 24mm x 24" Overall Length, 1.0079" Pilot Hole Diam, Square Broach
Item #: 37340171
Brand: Dumont Minute Man
Model #: 66643
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
| Product Specifications | |
|---|---|
| Square Size (mm) | 24.00 |
| Pilot Hole Diameter (Decimal Inch) | 1.0079 |
| Minimum Length of Cut (Inch) | 5/8 |
| Maximum Length of Cut (Inch) | 2 |
| Minimum Dimension Across Corners (Decimal Inch) | 1.3230 |
| Maximum Dimension Across Corners (Decimal Inch) | 1.3250 |
| Overall Length (Inch) | 24 |
| Pressure Required for Maximum Length of Cut (Lb.) | 9200 |
| Tooth Pitch (Inch) | 7/16 |
| Minimum Tolerance (Decimal Inch) | 0.9453 |
| Maximum Tolerance (Decimal Inch) | 0.9460 |
| Broach Material | High Speed Steel |
