Turning Insert: SPMT321EFB T1500Z, Cermet AlN Finish, Neutral, 0.3750″ Long, 3/8″ Inscribed Circle, 0.0157″ Corner Radius, 90.0 ° N/A Square, Series T1500Z
Item #: 23223597
Brand: Sumitomo
Model #: 194ACJT
Product Specifications
| Insert Style | SPMT |
| Insert Size Code | 321 |
| Insert Shape | Square |
| Insert Material | Cermet |
| Manufacturer Grade | T1500Z |
| Hole Diameter (Decimal Inch) | 0.1339 |
| Inscribed Circle (Inch) | 3/8 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Insert Holding Method | Screw |
| Insert Hand | Neutral |
| Insert Thickness (Decimal Inch) | 0.1252 |
| Corner Radius (Decimal Inch) | 0.0157 |
| Included Angle | 90.0 |
| Relief Angle | 11 |
| Series | T1500Z |
| Rake | Positive |
| Insert Length (Inch) | 3/8 |
| Insert Length (Decimal Inch) | 0.3750 |
| Primary Workpiece Material Code | P; K; M |
| Secondary Workpiece Material Code | P; K; M |
| Ansi Code | SPMT321EFBT1500Z |
| Chip Breaker | EFB |
| Coating/Finish | AlN |
