Dumont Minute Man - 9mm x 9" Overall Length, 0.3701" Pilot Hole Diam, Square Broach
Item #: 41848557
Brand: Dumont Minute Man
Model #: 66639
Features and Benefits
High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
| Product Specifications | |
|---|---|
| Square Size (mm) | 9.00 |
| Pilot Hole Diameter (Decimal Inch) | 0.3701 |
| Minimum Length of Cut (Inch) | 3/8 |
| Maximum Length of Cut (Inch) | 1-1/4 |
| Minimum Dimension Across Corners (Decimal Inch) | 0.4970 |
| Maximum Dimension Across Corners (Decimal Inch) | 0.4990 |
| Overall Length (Inch) | 9 |
| Pressure Required for Maximum Length of Cut (Lb.) | 3500 |
| Tooth Pitch (Inch) | 1/4 |
| Minimum Tolerance (Decimal Inch) | 0.3543 |
| Maximum Tolerance (Decimal Inch) | 0.3551 |
| Broach Material | High Speed Steel |
