Riten - Live Centers; Shank Type: Morse Taper ; Taper Size: 4MT ; Point Style: Male ; Point Diameter (Decimal Inch): 1.3840 ; Point Length (Decimal Inch): 1.5650 ; Accuracy (Decimal Inch): 0.000200
Item #: 20155693
Brand: Riten
Model #: G40-4
Product Specifications
Live Centers; Shank Type: Morse Taper ; Taper Size: 4MT ; Point Style: Male ; Point Diameter (Decimal Inch): 1.3840 ; Point Length (Decimal Inch): 1.5650 ; Accuracy (Decimal Inch): 0.000200
| Shank Type | Morse Taper |
| Taper Size | 4MT |
| Point Style | Male |
| Point Diameter (Decimal Inch) | 1.3840 |
| Point Length (Decimal Inch) | 1.5650 |
| Accuracy (Decimal Inch) | 0.000200 |
| Head Diameter (Inch) | 2-7/8 |
| Head Length (Inch) | 2-1/2 |
| Thread Size | 1-1/4 - 20 |
| Gage Line Clearance (Decimal Inch) | 0.2520 |
| Bearing Type | Sealed |
