Kyocera SNMG 321 PV710 Grade PVD Cermet, 0 Degree, Square, Negative Rake Angle, Neutral Turning Insert for Continuous and Roughing in (P) Carbon/Alloy Steel
Item #: 18256925
Brand: Kyocera
Model #: TLF05314
Product Specifications
| Insert Style | SNMG |
| Insert Shape Code | S |
| Insert Size Code | 321 |
| Insert Shape | Square |
| Clearance Code | N |
| Tolerance Code | M |
| Insert Material | Cermet |
| Manufacturer Grade | PV710 |
| Hole Diameter (Decimal Inch) | 0.1500 |
| Inscribed Circle (Inch) | 3/8 |
| Insert Holding Method | Screw; Clamp |
| Width (Inch) | 3/8 |
| Insert Hand | Neutral |
| Insert Thickness (Decimal Inch) | 0.1252 |
| Corner Radius (Decimal Inch) | 0.0157 |
| Included Angle | 90.0 |
| Relief Angle | 0 |
| Rake | Negative |
| Insert Length (Inch) | 3/8 |
| Primary Workpiece Material | P |
| Iso Code | SNMG090304 |
| Manufacturers Catalog Number | SNMG321PV710 |
| Chip Breaker | G |
| Style | SNMG |
| Full Radius | No |
| Coating/Finish | TiCN (Megacoat Nano) |
| Multi-Use Application | External Turning; Chamfering; Facing; Boring |
