RCGT0803M0-PM2 WK1 Carbide Turning Insert Uncoated, 8mm Inscribed Circle, 1/8″ Thick, Round, Series Tiger-tec
Item #: 16360281
Brand: Walter
Model #: 8132989
Product Specifications
| Insert Style | RCGT |
| Insert Shape Code | R |
| Insert Size Code | 0803 |
| Insert Shape | Round |
| Clearance Code | C |
| Tolerance Code | G |
| Insert Material | Solid Carbide |
| Manufacturer Grade | WN10 |
| Hole Diameter (Decimal Inch) | 0.1340 |
| Maximum Depth of Cut (mm) | 3.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.1181 |
| Inscribed Circle (mm) | 8.00 |
| Inscribed Circle (Decimal Inch) | 0.3150 |
| Insert Holding Method | Screw |
| Insert Hand | Neutral |
| Insert Thickness (Inch) | 1/8 |
| Insert Thickness (Decimal Inch) | 0.1250 |
| Corner Radius (Decimal Inch) | 0.1570 |
| Relief Angle | 7 |
| Series | RCGT |
| Coating Process | PVD |
| Rake | Positive |
| Primary Workpiece Material | Non-Ferrous Metal |
| Primary Workpiece Material Code | N |
| Secondary Workpiece Material | Super-alloys & Titanium |
| Secondary Workpiece Material Code | S |
| Ansi Code | RCGT0803M0PM2WK1 |
| Iso Code | RCGT0803M0-PM2 WK1 |
| Standards | ISO; ANSI |
| Manufacturers Catalog Number | RCGT0803M0-PM2 |
| Material Grade | S10; N10 |
| Chip Breaker | MN2 |
| Cutting Edge Style | Sharp |
| Single Or Double End | Single |
| Multi-Use Tool | Yes |
| Coating/Finish | Uncoated |
| Multi-Use Application | Turning |
 | |
| MSC Part # | 16360281 |
| Mfr Part # | 8132989 |
| Country of OriginCountry of Origin is subject to change | Germany |
