Screw Machine Length Drill Bit: 140 °, Solid Carbide Bright/Uncoated, Right Hand Cut, Helical Flute, Straight-Cylindrical Shank, Series K210
Item #: 13210711
Brand: Kennametal
Model #: 6351163
Product Specifications
| Drill Bit Size (mm) | 5.11 |
| Tool Material | Solid Carbide |
| Cutting Direction | Right Hand |
| Coating/Finish | Bright/Uncoated |
| Drill Point Angle | 140 |
| Flute Type | Helical |
| Coolant Through | Yes |
| Shank Type | Straight-Cylindrical |
| Number Of Flutes | 2 |
| Shank Diameter (Decimal Inch) | 0.2500 |
| Overall Length (mm) | 73.00 |
| Overall Length (Decimal Inch) | 2.8740 |
| Shank Diameter (mm) | 6.35 |
| Series | K210 |
| Maximum Drilling Depth (Decimal Inch) | 1.0197 |
| Maximum Drilling Depth (mm) | 25.90 |
| Shank Length (Decimal Inch) | 1.4370 |
| Shank Length (mm) | 36.50 |
| Drill Point Length (mm) | 0.76 |
| Drill Point Length (Decimal Inch) | 0.0299 |
| Flute By Diameter Ratio | 5xD |
| Flute Length (Decimal Inch) | 1.3386 |
| Flute Length (mm) | 34.00 |
| Drill Bit Size Range (Decimal Inch) | 0.2000 to 0.2500 |
