Bison - 6 Jaws, 10" Diam, Self Centering Manual Lathe Chuck - Front Mount, Adjustable, Reversible, 1,900 Max RPM, 2.992" Through Hole Diam, Forged Steel
Item #: 08610040
Brand: Bison
Model #: 7-868-1000
Exact Tooling IR#: 04
Features and Benefits
Self-centering scroll chucks are designed with jaws on a scroll which open and close with a wrench that is turned on a pinion. They accurately self-center on the workpiece as the jaws close.
Forged steel or steel chucks have greater accuracy, less wear and can be operated at higher RPM's.
| Product Specifications | |
|---|---|
| Chuck Type | Self-Centering |
| Nominal Chuck Size | 10 |
| Number of Jaws | 6 |
| Mount | Front Mount |
| Through-Hole Diameter (Decimal Inch) | 2.9920 |
| Body Material | Forged Steel |
| Reversible Jaws | Reversible Jaws |
| Number of Jaw Pieces | Two-Piece |
| Chuck Diameter (mm) | 254.00 |
| Chuck Diameter (Inch) | 10 |
| Adjustable | Yes |
| Jaw Type | Master Jaws; Top Jaws |
| TIR Repeatability (Decimal Inch) | 0.0006 |
| Body Length (Decimal Inch) | 3.5040 |
| Maximum RPM | 1900 |
| Includes | (2) 5" Eye Bolts; (2) Hex Keys; 6" Eye Bolt; Chuck Wrench; Set of Fine Adjustment Screws; Set of Hard Master Jaws; Set of Hard Top Reversible Jaws; Set of Mounting Bolts |
