Riten - Live Centers; Shank Type: Morse Taper ; Taper Size: 5MT ; Point Style: Male ; Point Diameter (Decimal Inch): 1.8840 ; Point Length (Decimal Inch): 2.0620 ; Accuracy (Decimal Inch): 0.000200
Item #: 08040594
Brand: Riten
Model #: G50-5
Product Specifications
Live Centers; Shank Type: Morse Taper ; Taper Size: 5MT ; Point Style: Male ; Point Diameter (Decimal Inch): 1.8840 ; Point Length (Decimal Inch): 2.0620 ; Accuracy (Decimal Inch): 0.000200
| Shank Type | Morse Taper |
| Taper Size | 5MT |
| Point Style | Male |
| Point Diameter (Decimal Inch) | 1.8840 |
| Point Length (Decimal Inch) | 2.0620 |
| Accuracy (Decimal Inch) | 0.000200 |
| Head Diameter (Inch) | 3-3/4 |
| Head Length (Decimal Inch) | 3.0630 |
| Thread Size | 1-1/2 - 20 |
| Gage Line Clearance (Decimal Inch) | 0.2550 |
| Bearing Type | Sealed |
