Associated Spring Raymond - 1-1/4" Hole Diam, 5/8" Rod Diam, 10" Free Length, Gold Die Spring - 768 Lb Max Deflection, 3" Max Deflection, Heavy Duty, Chromium Alloy Steel
Item #: 07662976
Brand: Associated Spring Raymond
Model #: 105-640
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Hole Diameter (Inch) | 1-1/4 |
| Rod Diameter (Inch) | 5/8 |
| Free Length (Inch) | 10 |
| Load Type | Heavy-Duty |
| Color | Gold |
| Maximum Deflection Load (Lb.) | 768.00 |
| Maximum Deflection (Decimal Inch) | 3.0000 |
| Wire Shape | Trapezoidal |
| Material | Chromium Alloy Steel |
