Philips Advance - 1 Lamp, 120 Volt, 0.14 to 0.19 Amp, 0 to 39 Watt, Preheat, Magnetic, Nondimmable Fluorescent Ballast - 0.89, 0.96, 1.00, 1.01, 1.02, 1.06 Ballast Factor, Thermal Protection, T5, T7, T9 Lamp
Item #: 03749769
Brand: Philips Advance
Model #: LPL5-9TPM
Exact Tooling IR#: 04
Features and Benefits
Preheat ballasts are used with either a starter or manual switch to establish a current through the ballast to the lamp. The preheat ballast will maintain the lamp current to the proper operating level once turned on.
| Product Specifications | |
|---|---|
| Lamp Type | T5; T7; T9 |
| Lamp Wattage Range | 0-39 |
| Voltage | 120 |
| Number of Lamps | 1 |
| Lamp Starting Method | Preheat Ballast |
| Ballast Factor Range | Normal (0.75-0.99) & Normal/High (1.00-1.19) |
| Dimmability | NonDimmable |
| Ballast Type | Magnetic |
| Lamp Wattage | 4; 5; 6; 7; 8; 9 |
| Amperage Range | 0.14-0.19 |
| Ballast Factor | 0.89; 0.96; 1.00; 1.01; 1.02; 1.06 |
| Minimum Starting Temperature (F) | 0; 25; 50 |
| Total Harmonic Distortion (%) | <10 |
| Can Code | H (2.375 x 1.375 x 1.375) |
| Additional Information | Thermal Protection |
