LDI Industries - 1 Outlet, Polymer Bowl, 3.79 L No Flow Control Oil Reservoir - 1/2 NPTF Outlet, 5-1/2" Diam x 15-1/4" High, 60°C Max
Item #: 03239837
Brand: LDI Industries
Model #: R113-04
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | No Flow Control Oil Reservoir |
| Number of Outlets | 1 |
| Bowl Material | Polymer |
| Capacity Range | 1 Gal. - 4.9 Gal. |
| Mount Type | Direct Mount |
| Outlet Thread Size | 1/2 |
| Outlet Thread Type | NPTF |
| Capacity (L) | 3.79 |
| Capacity (Gal.) | 1.00 |
| Diameter (mm) | 139.70 |
| Diameter (Inch) | 5-1/2 |
| Diameter (Decimal Inch) | 5.5000 |
| Height (mm) | 387.35 |
| Height (Inch) | 15-1/4 |
| Height (Decimal Inch) | 15.2500 |
| Maximum Operating Temperature (F) | 140.00 |
| Maximum Operating Temperature (C) | 60.00 |
| Components Material | Aluminum |
