LDI Industries - 1 Outlet, Polymer Bowl, 40.7 mL No Flow Control Oil Reservoir - 1/4 NPTF Outlet, 1-3/4" Diam x 2-61/64" High, 60°C Max
Item #: 03239639
Brand: LDI Industries
Model #: R152-02
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | No Flow Control Oil Reservoir |
| Number of Outlets | 1 |
| Bowl Material | Polymer |
| Capacity Range | Smaller than 16 oz. |
| Mount Type | Direct Mount |
| Outlet Thread Size | 1/4 |
| Outlet Thread Type | NPTF |
| Capacity (oz.) | 1.38 |
| Capacity (mL) | 40.70 |
| Diameter (mm) | 44.45 |
| Diameter (Inch) | 1-3/4 |
| Diameter (Decimal Inch) | 1.7500 |
| Height (mm) | 75.01 |
| Height (Inch) | 2-61/64 |
| Height (Decimal Inch) | 2.9531 |
| Maximum Operating Temperature (F) | 140.00 |
| Maximum Operating Temperature (C) | 60.00 |
| Components Material | Aluminum |
