Dayton Lamina - 7/8" ID x 2-7/16" OAL, Steel, Die & Mold Shoulder Bushing - Shoulder, 1-27/64" Bottom OD, 1-3/8" Top OD, 1-35/64" Collar OD, 1-3/4" Under Collar, 11/16" Above Collar
Item #: 03224631
Brand: Dayton Lamina
Model #: 6-07-64
Exact Tooling IR#: 04
Features and Benefits
Steel is made up of an iron and carbon. It offers high tensile strength and corrosion resistance, but may offer some vibration during an operation.
| Product Specifications | |
|---|---|
| Material | Steel |
| Inside Diameter (Inch) | 7/8 |
| Inside Diameter (Decimal Inch) | 0.8750 |
| Overall Length (Inch) | 2-7/16 |
| Overall Length (Decimal Inch) | 2.4375 |
| Body Type | Shoulder |
| Bottom Outside Diameter (Decimal Inch) | 1.4220 |
| Top Outside Diameter (Inch) | 1-3/8 |
| Top Outside Diameter (Decimal Inch) | 1.3750 |
| Attachment Method | Demountable |
| Lubrication Type | Non-Self Lubricating |
| Bushing Type | Friction |
| Collar Outside Diameter (Decimal Inch) | 1.5470 |
| Length Above Collar (Inch) | 11/16 |
| Length Under Collar (Inch) | 1-3/4 |
| Clamp Compatibility | 6-95-1 |
