Boston Gear - 20 Pitch, 3/4" Pitch Diam, 0.821" OD, 15 Tooth Helical Gear - 9/16" Face Width, 7/16" Bore Diam, 14.5° Pressure Angle, Steel
Item #: 01218494
Brand: Boston Gear
Model #: 18240
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Helical Gear |
| Number of Teeth | 15 |
| Pitch Diameter (Decimal Inch) | 0.7500 |
| Bore Diameter (Inch) | 7/16 |
| Bore Diameter (Decimal Inch) | 0.4375 |
| Material | Steel |
| Face Width (Inch) | 9/16 |
| Pressure Angle | 14.5 |
| PSC Code | 3020 |
