Suburban Tool - 3-1/2" Wide x 6" Deep x 3" High Steel Precision-Ground Angle Plate - Standard Plate, Machined Holes on Surface, Open End, Pair of Plates
Item #: 00442756
Brand: Suburban Tool
Model #: C36M
Exact Tooling IR#: 04
Features and Benefits
Steel is a sting and durable material used for general purpose applications.
Precision ground plates are used for close tolerance layout and inspection set-up.
Slotted angle plates are designed with clamping slots for mounting, layout and inspection operations. They can be used as backing plates and constructed with varying spacing between slots and holes.
| Product Specifications | |
|---|---|
| Width (Inch) | 3-1/2 |
| Depth (Inch) | 6 |
| Height (Inch) | 3 |
| Material | Steel |
| Finish Type | Precision-Ground |
| Plate Surface | Machined Holes |
| Plate Style | Standard |
| Plate Design | Open End |
| Number of Holes | 27 |
| Parallelism (Decimal Inch) | 0.0002 |
| Squareness (Decimal Inch) | 0.0002 |
| Hole Size | 1/4-20 |
| Single or Pair | Pair |
