RivetKing - #6-32 UNC Thread, Clear Zinc Plated, Steel, Screwdriver Installed Rivet Nut - 0.06 to 0.085" Grip, 15/32" Flange Diam, 0.9" Long
Item #: 00070045
Brand: RivetKing
Model #: JK-0402
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| System of Measurement | Inch |
| Thread Size (Inch) | #6-32 |
| Minimum Grip (Decimal Inch) | 0.0600 |
| Maximum Grip (Decimal Inch) | 0.0850 |
| Flange Diameter (Decimal Inch) | 0.4690 |
| Flange Thickness (Decimal Inch) | 0.0730 |
| Overall Length (Decimal Inch) | 0.9000 |
| Material | Steel |
| Finish/Coating | Clear; Zinc-Plated |
| Body Diameter (Decimal Inch) | 0.3080 |
| Thread Standard | UNC |
