Indexable Cutting Tools - Indexable Inserts For Sale | Exact Tool & Supply - (25001 Products)

Hertel - 16ER External Right Hand 48-16 Partial Profile 60° Laydown Threading Insert - Grade HG330TR, TiC/TiN Coated Carbide - Exact Tool & Supply

Hertel - 16ER External Right Hand 48-16 Partial Profile 60° Laydown Threading Insert - Grade HG330TR, TiC/TiN Coated Carbide


Item #: 53440582
Brand: Hertel
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Material Carbide
Insert Style 16ER
Insert Hand Right Hand
Thread Type External
Thread Standard Partial Profile 60
Manufacturer's Grade HG330TR
Threads Per Inch 48-16
Pitch (mm) 0.5-1.5
Inscribed Circle (Inch) 3/8
Inscribed Circle (Decimal Inch) 0.3750
Thickness (Decimal Inch) 0.1460
Coating TiC/TiN

$18.16

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Sandvik Coromant - 30N151.2-A.. 5P 1/8" Cutting Width Carbide Grooving Insert - 1.3mm Max Depth of Cut, Neutral, 1/16" Corner Radius, TiCN/Al2O3/TiN Finish - Exact Tool & Supply

Sandvik Coromant - 30N151.2-A.. 5P 1/8" Cutting Width Carbide Grooving Insert - 1.3mm Max Depth of Cut, Neutral, 1/16" Corner Radius, TiCN/Al2O3/TiN Finish


Item #: 52874880
Brand: Sandvik Coromant
Model #: 5736800
Exact Tooling IR#: 04

Features and Benefits

Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style N151.2-A..
Insert Size 30
Material Carbide
Cutting Width (mm) 3.18
Cutting Width (Inch) 1/8
Cutting Width (Decimal Inch) 0.1250
Maximum Depth of Cut (mm) 1.30
Maximum Depth of Cut (Decimal Inch) 0.0512
Coating TiCN/Al2O3/TiN
Insert Hand Neutral
Cutting Height (mm) 6.78
Cutting Height (Decimal Inch) 0.2672
Insert Seat Size 30
Chipbreaker 5P
Multi-Use Tool Yes
Multi-Use Application Grooving; Parting
Minimum Corner Radius (Decimal Inch) 0.0625
Corner Radius (mm) 1.58
Corner Radius (Inch) 1/16
Corner Radius (Decimal Inch) 0.0625
Coating Process MT-CVD
Series T-Max Q-Cut
Rake Positive
ISO Number N151.2-A125-30-5P 4225
Manufacturers Catalog Number N151.2-A125-30-5P 4225
Overall Width (Decimal Inch) 0.1250
Insert Thickness (Decimal Inch) 0.2672

$24.80

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Iscar - 16ER External Right Hand 16 UNJ Laydown Threading Insert - Grade IC908, TiAlN Coated Carbide, 9.53mm Inscribed Circle - Exact Tool & Supply

Iscar - 16ER External Right Hand 16 UNJ Laydown Threading Insert - Grade IC908, TiAlN Coated Carbide, 9.53mm Inscribed Circle


Item #: 86859071
Brand: Iscar
Model #: 5995220
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Material Carbide
Insert Style 16ER
Insert Hand Right Hand
Thread Type External
Thread Standard UNJ
Manufacturer's Grade IC908
Threads Per Inch 16
Inscribed Circle (mm) 9.53
Inscribed Circle (Inch) 3/8
Inscribed Circle (Decimal Inch) 0.3750
Thickness (Decimal Inch) 0.1430
Coating TiAlN
Coating Process PVD
Corner Radius (mm) 0.23
Corner Radius (Decimal Inch) 0.0090

$30.50

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Kennametal - APPT1604 GD Grade KCPK30 Carbide Milling Insert - TiN/TiCN/Al2O3 Finish, 0.2071" Thick, 0.8mm Corner Radius - Exact Tool & Supply

Kennametal - APPT1604 GD Grade KCPK30 Carbide Milling Insert - TiN/TiCN/Al2O3 Finish, 0.2071" Thick, 0.8mm Corner Radius


Item #: 04144796
Brand: Kennametal
Model #: 2527940
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style APPT
Insert Size 1604
Material Carbide
Material Grade C1/C5/C6
Manufacturer's Grade KCPK30
Coating TiN/TiCN/Al2O3
Width (Decimal Inch) 0.3713
Length (Decimal Inch) 0.6787
Thickness (Decimal Inch) 0.2071
Corner Radius (Decimal Inch) 0.0315
Corner Radius (mm) 0.80
Hole Diameter (mm) 4.40
Hole Diameter (Decimal Inch) 0.1732
Relief Angle 11.000
Rake Angle 15
Coating Process CVD
Included Angle 85
Shape Parallelogram
Insert Hand Right Hand
Chipbreaker GD
ISO Number APPT1604PDSRGD

$27.01

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Tool-Flo - 3047FLGP Grade GPM6B, 1.19mm Cutting Width Carbide Grooving Insert - 1.91mm Max Depth of Cut, Right Hand, 0.005 to 0.01" Corner Radius - Exact Tool & Supply

Tool-Flo - 3047FLGP Grade GPM6B, 1.19mm Cutting Width Carbide Grooving Insert - 1.91mm Max Depth of Cut, Right Hand, 0.005 to 0.01" Corner Radius


Item #: 68356120
Brand: Tool-Flo
Model #: 573447RP9B
Exact Tooling IR#: 04

Features and Benefits

Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style FLGP
Insert Size 3047
Material Carbide
Cutting Width (mm) 1.19
Cutting Width (Decimal Inch) 0.0470
Maximum Depth of Cut (mm) 1.91
Maximum Depth of Cut (Decimal Inch) 0.0750
Manufacturer's Grade GPM6B
Cutting Direction Right Hand
Insert Hand Right Hand
Cutting Height (Decimal Inch) 0.3440
Multi-Use Tool No
Minimum Corner Radius (Decimal Inch) 0.0050
Maximum Corner Radius (Decimal Inch) 0.0100
Corner Radius (Decimal Inch) 0.005-0.010
Series Flo-Lock
Rake Positive
Manufacturers Catalog Number FLGP-3047R
Insert Thickness (Decimal Inch) 0.1950

$33.12

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Walter - D57 Grade WKP35S Milling Insert - 4.76mm Thick, 12.7mm Inscribed Circle, 0.8mm Corner Radius - Exact Tool & Supply

Walter - D57 Grade WKP35S Milling Insert - 4.76mm Thick, 12.7mm Inscribed Circle, 0.8mm Corner Radius


Item #: 49596646
Brand: Walter
Model #: 6796072
Exact Tooling IR#: 04

Product Specifications
Manufacturer's Grade WKP35S
Length (mm) 12.70
Length (Decimal Inch) 0.5000
Inscribed Circle (mm) 12.70
Inscribed Circle (Decimal Inch) 0.5000
Thickness (mm) 4.76
Thickness (Decimal Inch) 0.1870
Corner Radius (Decimal Inch) 0.0310
Corner Radius (mm) 0.80
Hole Diameter (mm) 4.40
Hole Diameter (Decimal Inch) 0.1730
Relief Angle 15.000
Coating Process CVD
Insert Hand Neutral
Chipbreaker D57
Maximum Depth of Cut (mm) 12.70
Maximum Depth of Cut (Decimal Inch) 0.5000
Manufacturers Catalog Number SDMT120408-D57 WKP35S

$21.00

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Tool-Flo - 3FLG P Grade AC3R, 3.2mm Cutting Width Carbide Grooving Insert - 4.57mm Max Depth of Cut, Right Hand, 0.005 to 0.01" Corner Radius, TiAlN Finish - Exact Tool & Supply

Tool-Flo - 3FLG P Grade AC3R, 3.2mm Cutting Width Carbide Grooving Insert - 4.57mm Max Depth of Cut, Right Hand, 0.005 to 0.01" Corner Radius, TiAlN Finish


Item #: 68356906
Brand: Tool-Flo
Model #: 563M320PRAC3R
Exact Tooling IR#: 04

Features and Benefits

Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style FLG
Insert Size 3
Material Carbide
Cutting Width (mm) 3.20
Cutting Width (Decimal Inch) 0.1260
Maximum Depth of Cut (mm) 4.57
Maximum Depth of Cut (Decimal Inch) 0.1799
Manufacturer's Grade AC3R
Coating TiAlN
Cutting Direction Right Hand
Insert Hand Right Hand
Cutting Height (Decimal Inch) 0.3440
Chipbreaker P
Multi-Use Tool No
Minimum Corner Radius (Decimal Inch) 0.0050
Maximum Corner Radius (Decimal Inch) 0.0100
Corner Radius (Decimal Inch) 0.005-0.010
Coating Process PVD
Series Flo-Lock
ISO Number FLG-3M320R-CB
Manufacturers Catalog Number FLG-3M320R-CB
Insert Thickness (Decimal Inch) 0.1950

$24.59

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Tool-Flo - 2031FLGP Grade AC50C, 0.79mm Cutting Width Carbide Grooving Insert - 1.27mm Max Depth of Cut, Left Hand, 0.002 to 0.005" Corner Radius, AlTiN Finish - Exact Tool & Supply

Tool-Flo - 2031FLGP Grade AC50C, 0.79mm Cutting Width Carbide Grooving Insert - 1.27mm Max Depth of Cut, Left Hand, 0.002 to 0.005" Corner Radius, AlTiN Finish


Item #: 68356302
Brand: Tool-Flo
Model #: 572431LAC50C
Exact Tooling IR#: 04

Features and Benefits

Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style FLGP
Insert Size 2031
Material Carbide
Cutting Width (mm) 0.79
Cutting Width (Decimal Inch) 0.0310
Maximum Depth of Cut (mm) 1.27
Maximum Depth of Cut (Decimal Inch) 0.0500
Manufacturer's Grade AC50C
Coating AlTiN
Cutting Direction Left Hand
Insert Hand Left Hand
Cutting Height (Decimal Inch) 0.2190
Multi-Use Tool No
Minimum Corner Radius (Decimal Inch) 0.0020
Maximum Corner Radius (Decimal Inch) 0.0050
Corner Radius (Decimal Inch) 0.002-0.005
Coating Process PVD
Series Flo-Lock
Rake Positive
Manufacturers Catalog Number FLGP-2031L
Insert Thickness (Decimal Inch) 0.1500

$27.87

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Sandvik Coromant - F2N123 GF Grade 1125, 2.65mm Cutting Width Carbide Grooving Insert - 19.2mm Max Depth of Cut, Neutral, 0.2mm Corner Radius, TiAlN Finish - Exact Tool & Supply

Sandvik Coromant - F2N123 GF Grade 1125, 2.65mm Cutting Width Carbide Grooving Insert - 19.2mm Max Depth of Cut, Neutral, 0.2mm Corner Radius, TiAlN Finish


Item #: 54844899
Brand: Sandvik Coromant
Model #: 5735609
Exact Tooling IR#: 04

Features and Benefits

Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style N123
Insert Size F2
Material Carbide
Cutting Width (mm) 2.65
Cutting Width (Decimal Inch) 0.1043
Maximum Depth of Cut (mm) 19.20
Maximum Depth of Cut (Decimal Inch) 0.7559
Manufacturer's Grade 1125
Coating TiAlN
Cutting Direction Neutral
Insert Hand Neutral
Lead Angle 0
Relief Angle 7
Insert Seat Size F
Chipbreaker GF
Multi-Use Tool Yes
Multi-Use Application Parting
Corner Radius (mm) 0.20
Corner Radius (Decimal Inch) 0.0079
Coating Process PVD
Series CoroCut 1-2
ISO Number N123F202650002GF1125
Manufacturers Catalog Number 5735609
Insert Thickness (Decimal Inch) 0.1693
Insert Thickness (mm) 4.3000

$49.00

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Kennametal - SPHX15T6 Grade K125M Carbide Milling Insert - Uncoated, 0.2598" Thick, 15mm Inscribed Circle - Exact Tool & Supply

Kennametal - SPHX15T6 Grade K125M Carbide Milling Insert - Uncoated, 0.2598" Thick, 15mm Inscribed Circle


Item #: 63714364
Brand: Kennametal
Model #: 1223439
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style SPHX
Insert Size 15T6
Material Carbide
Material Grade C5
Manufacturer's Grade K125M
Coating Uncoated
Inscribed Circle (mm) 15.00
Inscribed Circle (Decimal Inch) 0.5906
Thickness (Decimal Inch) 0.2598
Hole Diameter (mm) 6.00
Hole Diameter (Decimal Inch) 0.2362
Relief Angle 11.000
Rake Angle 30
Included Angle 90
Shape Square
ISO Number SPHX15T6ZCSRGP

$46.56

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Kennametal - 2125NG K Grade KC5025, 3.18mm Cutting Width Carbide Grooving Insert - 2.79mm Max Depth of Cut, Left Hand, 0.19mm Corner Radius, TiAlN Finish - Exact Tool & Supply

Kennametal - 2125NG K Grade KC5025, 3.18mm Cutting Width Carbide Grooving Insert - 2.79mm Max Depth of Cut, Left Hand, 0.19mm Corner Radius, TiAlN Finish


Item #: 03822434
Brand: Kennametal
Model #: 1818041
Exact Tooling IR#: 04

Features and Benefits

Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style NG
Insert Size 2125
Material Carbide
Cutting Width (mm) 3.18
Cutting Width (Decimal Inch) 0.1252
Maximum Depth of Cut (mm) 2.79
Maximum Depth of Cut (Decimal Inch) 0.1098
Material Grade C2/C6
Manufacturer's Grade KC5025
Coating TiAlN
Insert Hand Left Hand
Lead Angle 3
Insert Seat Size 2
Chipbreaker K
Multi-Use Tool No
Corner Radius (mm) 0.19
Corner Radius (Decimal Inch) 0.0075
Coating Process PVD
Series Top Notch
Rake Angle 10
Rake Positive
Included Angle 55

$30.40

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Tungaloy - 16IR Internal Right Hand Whitworth Laydown Threading Insert - Grade AH725, TiAlN Coated Carbide - Exact Tool & Supply

Tungaloy - 16IR Internal Right Hand Whitworth Laydown Threading Insert - Grade AH725, TiAlN Coated Carbide


Item #: 47611686
Brand: Tungaloy
Model #: 6859782
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Material Carbide
Insert Style 16IR
Insert Hand Right Hand
Thread Type Internal
Thread Standard Whitworth
Manufacturer's Grade AH725
Internal Threads Per Inch 12
Inscribed Circle (Inch) 3/8
Inscribed Circle (Decimal Inch) 0.3750
Thickness (Decimal Inch) 0.0630
Thickness (mm) 1.60
Coating TiAlN
Coating Process PVD
Corner Radius (mm) 0.27
Corner Radius (Decimal Inch) 0.0106
Series TAC; TungThread

$26.75

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Vargus - 3ER External Right Hand ISO Laydown Threading Insert - Grade VTX, TiAlN Coated Carbide, 9.53mm Inscribed Circle - Exact Tool & Supply

Vargus - 3ER External Right Hand ISO Laydown Threading Insert - Grade VTX, TiAlN Coated Carbide, 9.53mm Inscribed Circle


Item #: 80856289
Brand: Vargus
Model #: 53608
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Material Carbide
Insert Style 3ER
Insert Hand Right Hand
Thread Type External
Thread Standard ISO
Material Grade Micrograin
Manufacturer's Grade VTX
Pitch (mm) 0.80
Inscribed Circle (mm) 9.53
Inscribed Circle (Decimal Inch) 0.3750
Thickness (mm) 3.60
Included Angle of Threading Tip 60
Coating TiAlN
Coating Process PVD
Number of Teeth Per Side 1

$21.63

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Kennametal - SDHT09T308 Grade X500 Carbide Milling Insert - TiN/TiC/TiN Finish - Exact Tool & Supply

Kennametal - SDHT09T308 Grade X500 Carbide Milling Insert - TiN/TiC/TiN Finish


Item #: 44094894
Brand: Kennametal
Model #: 5653138
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style SDHT
Insert Size 09T308
Material Carbide
Manufacturer's Grade X500
Coating TiN/TiC/TiN
Shape Square

$30.21

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Tungaloy - 27-178-018TCM Grade AH725, 1.78mm Cutting Width Carbide Grooving Insert - 3mm Max Depth of Cut, Right Hand, 0.18mm Corner Radius, TiAlN Finish - Exact Tool & Supply

Tungaloy - 27-178-018TCM Grade AH725, 1.78mm Cutting Width Carbide Grooving Insert - 3mm Max Depth of Cut, Right Hand, 0.18mm Corner Radius, TiAlN Finish


Item #: 47595053
Brand: Tungaloy
Model #: 6996675
Exact Tooling IR#: 04

Features and Benefits

Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style TCM
Insert Size 27-178-018
Material Carbide
Cutting Width (mm) 1.78
Cutting Width (Decimal Inch) 0.0700
Maximum Depth of Cut (mm) 3.00
Maximum Depth of Cut (Decimal Inch) 0.1180
Manufacturer's Grade AH725
Coating TiAlN
Insert Hand Right Hand
Cutting Height (mm) 3.00
Cutting Height (Decimal Inch) 0.1180
Multi-Use Application External Profiling; Grooving; Parting
Corner Radius (mm) 0.18
Corner Radius (Decimal Inch) 0.0070
Coating Process PVD
Series TetraFcut
ISO Number TCM27-178-018
Manufacturers Catalog Number TCM27-178-018

$53.05

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

LMT - XCNT070308 TR Grade LC630Q Carbide Milling Insert - AlCrN Finish, 0.1252" Thick, 5/16" Inscribed Circle, 0.8mm Corner Radius - Exact Tool & Supply

LMT - XCNT070308 TR Grade LC630Q Carbide Milling Insert - AlCrN Finish, 0.1252" Thick, 5/16" Inscribed Circle, 0.8mm Corner Radius


Item #: 42713776
Brand: LMT
Model #: 7011714
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style XCNT
Insert Size 070308
Material Carbide
Manufacturer's Grade LC630Q
Coating AlCrN
Inscribed Circle (Decimal Inch) 0.3126
Thickness (Decimal Inch) 0.1252
Corner Radius (Decimal Inch) 0.0315
Corner Radius (mm) 0.80
Hole Diameter (mm) 3.40
Hole Diameter (Decimal Inch) 0.1339
Relief Angle 7.000
Rake Angle 15
Rake Positive
Coating Process PVD
Shape Irregular
Chipbreaker TR
Cutting Edge Style Sharp

$34.03

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Seco - XOMX120408 ME08 Grade T350M Carbide Milling Insert - TiCN/Al2O3 Finish, 0.187" Thick, 0.031" Corner Radius - Exact Tool & Supply

Seco - XOMX120408 ME08 Grade T350M Carbide Milling Insert - TiCN/Al2O3 Finish, 0.187" Thick, 0.031" Corner Radius


Item #: 56973548
Brand: Seco
Model #: 03975
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style XOMX
Insert Size 120408
Material Carbide
Material Grade C5
Manufacturer's Grade T350M
Coating TiCN/Al2O3
Width (Decimal Inch) 0.3220
Length (Decimal Inch) 0.4790
Thickness (Decimal Inch) 0.1870
Corner Radius (Decimal Inch) 0.0310
Relief Angle 14.000
Rake Angle 25
Coating Process CVD
Included Angle 80
Shape Parallelogram
Insert Hand Right Hand
Chipbreaker ME08
ISO Number XOMX120408TR-ME08

$25.30

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Sandvik Coromant - EN123 GF Grade H13A, 2mm Cutting Width Carbide Grooving Insert - 19.2mm Max Depth of Cut, Neutral, 0.2mm Corner Radius, Uncoated - Exact Tool & Supply

Sandvik Coromant - EN123 GF Grade H13A, 2mm Cutting Width Carbide Grooving Insert - 19.2mm Max Depth of Cut, Neutral, 0.2mm Corner Radius, Uncoated


Item #: 45501236
Brand: Sandvik Coromant
Model #: 5735797
Exact Tooling IR#: 04

Features and Benefits

Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style N123
Insert Size E
Material Carbide
Cutting Width (mm) 2.00
Cutting Width (Decimal Inch) 0.0787
Maximum Depth of Cut (mm) 19.20
Maximum Depth of Cut (Decimal Inch) 0.7559
Manufacturer's Grade H13A
Coating Uncoated
Cutting Direction Neutral
Insert Hand Neutral
Cutting Height (mm) 4.30
Cutting Height (Decimal Inch) 0.1693
Relief Angle 7
Insert Seat Size E
Chipbreaker GF
Multi-Use Tool Yes
Multi-Use Application Parting; Grooving; Slitting; Slotting; Plunging
Minimum Corner Radius (Decimal Inch) 0.0059
Maximum Corner Radius (Decimal Inch) 0.0098
Corner Radius (mm) 0.2
Corner Radius (Decimal Inch) 0.0079
Coating Process Uncoated
Overall Length (mm) 20.05
Overall Length (Decimal Inch) 0.7894
Series CoroCut 1-2
Rake Angle 0
Rake Neutral
ISO Number N123E2-0200-0002-GF H13A
Manufacturers Catalog Number N123E2-0200-0002-GF H13A
Overall Width (mm) 2.00
Overall Width (Decimal Inch) 0.0787
Insert Thickness (Decimal Inch) 0.1693

$34.50

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Iscar - 11IRM Internal Right Hand ISO Laydown Threading Insert - Grade IC908, TiAlN Coated Carbide, 6.35mm Inscribed Circle - Exact Tool & Supply

Iscar - 11IRM Internal Right Hand ISO Laydown Threading Insert - Grade IC908, TiAlN Coated Carbide, 6.35mm Inscribed Circle


Item #: 63972061
Brand: Iscar
Model #: 5921233
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Material Carbide
Insert Style 11IRM
Insert Hand Right Hand
Thread Type Internal
Thread Standard ISO
Manufacturer's Grade IC908
Pitch (mm) 1.00
Inscribed Circle (mm) 6.35
Inscribed Circle (Inch) 1/4
Inscribed Circle (Decimal Inch) 0.2500
Thickness (Decimal Inch) 0.1260
Coating TiAlN
Coating Process PVD
Corner Radius (mm) 0.05
Corner Radius (Decimal Inch) 0.0020
Chipbreaker M

$22.20

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It

Kennametal - EC1004 LD Grade KC410M Carbide Milling Insert - TiB2 Finish, 0.148" Thick, 0.4mm Corner Radius - Exact Tool & Supply

Kennametal - EC1004 LD Grade KC410M Carbide Milling Insert - TiB2 Finish, 0.148" Thick, 0.4mm Corner Radius


Item #: 63220412
Brand: Kennametal
Model #: 3682450
Exact Tooling IR#: 04

Features and Benefits

Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
Product Specifications
Insert Style EC
Insert Size 1004
Material Carbide
Manufacturer's Grade KC410M
Coating TiB2
Width (Decimal Inch) 0.2660
Length (Decimal Inch) 0.4744
Thickness (Decimal Inch) 0.1480
Corner Radius (Decimal Inch) 0.0160
Corner Radius (mm) 0.40
Relief Angle 15.000
Rake Angle 15
Rake Positive
Coating Process PVD
Shape Parallelogram
Chipbreaker LD
ISO Number EDCT10T304PDFRLDJ

$26.82

2% Off All Online Orders
Use Code: 2%OFF

Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
