Brand: Ingersoll Cutting Tools / Part #: 5609815
Item #: 67323576
Brand: Ingersoll Cutting Tools
Model #: 5609815
Product Specifications
| Insert Style | RFMR |
| Insert Size Code | 1904 |
| Insert Material | Carbide |
| Manufacturer Grade | TT9030 |
| Inscribed Circle (mm) | 19.00 |
| Corner Radius (Inch) | 3/8 |
| Insert Hand | Neutral |
| Series | RFMR |
| Coating Process | PVD |
| Maximum Depth of Cut (Decimal Inch) | 0.3740 |
| Number Of Cutting Edges | 8 |
| Insert Shape | Round |
| Rake | Positive |
| Primary Workpiece Material | Stainless Steel; Super-alloys & Titanium; Steel |
| Primary Workpiece Material Code | P; S; M |
| Ansi Code | RFMR1904-M |
| Rake Angle | 25.000 |
| Manufacturers Catalog Number | RFMR1904-M TT9030 |
| Cutter Series Compatibility | 5N2L |
| Chip Breaker | M |
| Cutting Direction | Neutral |
| Shape | Round |
| Length of Cut (mm) | 9.5000 |
| Insert Holding Method | Screw |
| Coating Classification | PVD |
| Single or Double Sided Insert | Single |
| Coating/Finish | TiAlN |
| Length | 19.00 |
| Width (Mm - 2 Decimals) | 19.00 |
| Thickness (Decimal Inch - 4 Decimals) | 0.2080 |
| Multi-Use Tool | No |
