16IR G60 C22
Item #: FG322469358
Brand: Tool-Flo
Model #: 2469358
| Product Specifications | |
|---|---|
| Inscribed Circle Diameter (IC) | 3/8″ |
| Chip Breaker Type | Z |
| Insert Length (INSL) | 0.63″ |
| Shape | Triangle |
| Corner Radius (RE) | 0.0051″ |
| Threads per Inch Minimum (TPIN) | 8 Threads/" |
| Grade | C22 |
| Threads per Inch Maximum (TPIX) | 14 Threads/" |
| Coating | Uncoated |
| Tool Type | Threading Regular Inserts |
| Cutting Edge Material | Carbide |
| Measurement Type | Inch |
| Application | | Internal Thread Milling | Internal Threading lay down | Treading Inserts | |
| Body Material | Carbide |
| Applicable Material | | Stainless Steel | Non Ferrous Metals | Hi Temp Alloys | |
| Thread Form Type (THFT) | VP60 |
| Cutting Direction (HAND) | Right Hand |
